Link Hardware Heavy Duty Venice 180 Series Glass-to-Glass Hinge
SKU
V180
Categories Hinges, Link Hardware - All Products, Shower Hardware
- 180-degree glass-to-glass standard model hinges
- Hinges can swing 90 degrees in and 90 degrees out
- Self-centering when within 15o of closing position
- Suitable for use with tempered safety glass of thickness 3/8″ to 1/2″
- Two hinges with 3/8″ or 1/2″ glass can hold up to 110 lbs.
- Three hinges with 3/8″ or 1/2″ glass can hold up to 140 lbs.
- Made from solid brass
Link Hardware Venice 180 Series Glass-to-Glass Hinges are the perfect solution for larger and heavier doors that simply can’t be held up by traditional standard-sized hinges. They are suitable for tempered safety glass of thickness 3/8″ to 1/2,” and those as wide as 36″. Venice 180 Series Hinges allow doors to swing 90 degrees in and 90 degrees out, and are self-centering within 15 degrees of the closing position. They come with a reversible 5-degree pivot pin, which can be rotated to activate the other side and can either be removed or included based on preference.
Finish: BBRZ, BN, CH, MBL, ORB, PN, SB
